Shell and tube heat exchanger is vital in the oil and gas sector. Their ability to handle high-pressure and temperature applications makes them become a top priority to be implemented. For companies, the reliability of heat exchangers is vital for ensuring the smooth operation of various processes. In this article, we will serve thorough information regarding shell and tube heat exchanger covering their definition, components, and how they work.
What Is Shell and Tube Heat Exchanger?
A tube and heat exchanger is a device designed to transfer heat from one fluid to another fluid without them touching each other directly. This category of heat exchanger is named after its design, which includes a shell (as a sizable pressure vessel) housing a group of tubes.
The tubes are enclosed by another fluid, such as water or air, and heat is transferred from the first fluid to the second fluid through the tube walls. Tube and heat exchangers have various applications, such as in air conditioning systems, refrigeration systems, and industrial processes that require heat transfer.
What Are The Components of Shell and Tube Heat Exchanger?
The components of a shell and tube heat exchanger can be broken down into the following parts:
1. Shell
The shell is the heat exchanger’s outermost part which holds the tube bundle. It is commonly a cylindrical container constructed from steel or other appropriate substances
2. Tubes or Tube Bundle
A collection of parallel tubes running along the length of the shell makes up the tube bundle. Depending on the specific use, the tubes can be composed of different materials, such as stainless steel, copper, or titanium. The diameter and thickness of the tubes are also important design parameters.
3. Tube Sheets
Tube sheets are sturdy sheets that act as a barrier between the tube bundle and the shell. They are commonly constructed using steel and are fused to the shell to ensure a firm and leak-free closure. The tubes are inserted through holes in the tube sheets and are either expanded or welded in position.
4. Baffles
Baffles are plates or rods that are placed inside the shell to regulate the movement of fluid around the tube bundle. These can be either longitudinal or transverse in orientation and are intended to enhance the effectiveness of heat transfer.
5. Inlet and Outlet Nozzles
The inlet and outlet nozzles serve as the entry and exit points for fluids in the heat exchanger. These connections are usually placed at opposite ends of the shell and are attached to the tubes and the shell using flanges or other types of fittings.
6. Expansion Joints
Expansion joints are flexible connectors that accommodate the tube bundle’s thermal expansion and contraction. Usually situated at the inlet and outlet of the heat exchanger, these joints are constructed using metal bellows or other flexible materials.
7. Support Structures
Support structures hold heat exchangers in position, ensuring a stable foundation. Support structures can be either temporary or permanent and may be made of steel or other materials.
What Are Some Types of Shell and Tube Heat Exchangers?
There are different types of shell and tube heat exchangers classified based on their design and intended use, as defined by the Tubular Exchangers Manufacturers Association (TEMA). These categories help in understanding the specific applications and requirements of each type:
1. Class B
These heat exchangers are designed for chemical processing applications. They are constructed with materials and configurations suitable for handling corrosive substances and demanding chemical processes. Class B heat exchangers are built to withstand the challenges posed by chemical environments.
2. Class C
This category encompasses heat exchangers intended for general commercial applications. These heat exchangers are versatile and can be used in various industries where moderate operating conditions are present. They are designed to efficiently exchange heat in common commercial settings.
3. Class R
Heat exchangers classified under Class R are specifically tailored for petroleum and large-scale applications. They are engineered to handle the rigorous demands of processing petroleum products, including high temperatures, pressures, and flow rates. Class R heat exchangers are robust and suitable for industrial-scale operations.
TEMA organizes shell and tube heat exchangers based on their components like the front end (head), rear end, and the shell. They use a chart with columns and rows to describe each type. To simplify identification, TEMA created a three-letter system (BEM, AEM, or NEN) for different designs of straight tube and fixed tube sheet heat exchangers.
The first letter in the code describes how the front end stationary head is connected to the shell and channel—either bolted (B) or welded (W). The second letter indicates the type of shell, including inlet/outlet positions, presence of baffles, and distribution plates. The third letter specifies the rear end head type and how the shell connects to the second tube sheet—bolted (B) or welded (W).
For example, a BEM heat exchanger has a bonnet header, a one-pass shell, and a fixed tube sheet, all identified using the TEMA system for clear categorization and understanding of different heat exchanger designs.
Understanding these classifications helps in selecting the appropriate shell and tube heat exchanger for specific industrial needs, ensuring optimal performance, reliability, and longevity in heat exchange processes.
How Does Shell and Tube Heat Exchanger Work?
Shell and tube heat exchanger works by transferring heat between two fluids, such as liquids or gasses. The fluids are separated by a solid barrier and flow through separate channels. One fluid travels through tubes while the other flows around the tubes in the shell.
While the fluids flow through their channels, the heat is transferred from the hotter fluid to the cooler fluid through the barrier because of temperature differences and the barrier’s conductive properties of the solid barrier.
The shell and tube design provides a large surface area for heat transfer, making it an efficient method to carry the heat between fluids. Furthermore, the tubes can be removed for cleaning or replacement without affecting the shell, which makes it easy to maintain and clean.
What Are The Advantages of A Shell and Tube Heat Exchanger?
The advantages of a shell and tube heat exchanger include its simple design, robust characteristics, and relatively low purchase and maintenance costs. This type of heat exchanger is widely used in various cooling applications due to these benefits.
The simple design of a shell-and-tube heat exchanger makes it versatile and suitable for a range of cooling needs. It is commonly used to cool hydraulic fluid and oil in engines, transmissions, and hydraulic power packs. Additionally, with the right choice of materials, these heat exchangers can also be used to cool or heat other mediums such as swimming pool water or charge air.
One of the significant advantages of shell-and-tube heat exchangers is their ease of service, especially models with a floating tube bundle design where the tube plates are not welded to the outer shell. This makes maintenance and cleaning more accessible, contributing to efficient operation and extended lifespan. Furthermore, the cylindrical design of the housing provides excellent resistance to pressure, making shell-and-tube heat exchangers suitable for a wide range of pressure applications in various industries.
